MSD 62013 - Ignition Control Module
New Car Parts
Details
The MSD 62013 6AL-2 represents MSD's advanced digital ignition control technology, featuring programmable multi-step rev limiting and built-in timing control. This unit provides enhanced spark energy and precision timing control for high-performance racing and competitive applications.
Technical Specifications:
- Input Voltage Range: 12-18V DC
- Maximum Output Voltage: 530-540V
- Spark Energy Output: Up to 160 mJ per spark
- RPM Range: 0-12,800 RPM
- Multiple Spark Duration: Up to 3,000 RPM
- Current Draw:
- Idle: 1.2A @ 12V
- Maximum: 22A @ 12V
- Dimensions: 8.23" x 4.5" x 2.2"
- Weight: 2.9 lbs
- Operating Temperature: -20°F to +185°F
- Internal Memory: Non-volatile
Advanced Features:
- 2-Step Rev Limiting Control
- Built-in Start Retard (0-20°)
- RPM-Activated Switch Output
- Digital Timing Control
- PC Programmable via USB
- Data Recording Capability
- LED Status Indicators
- Advanced EMI/RFI Suppression
Interface Capabilities:
- USB Programming Port
- Magnetic Pickup Input
- Points/Amplifier Trigger Input
- Tach Output Signal
- Launch Control Input
- Time-Based Retard
- Step Retard Input
- RPM-Activated Output
Performance Functions:
- Programmable Rev Limits
- Adjustable Start Retard
- Launch Control Settings
- Boost Timing Control
- Individual Cylinder Timing
- Real-Time Monitoring
- Diagnostic Functions
Application Compatibility:
- Circle Track Racing
- Drag Racing
- Marine Applications
- Off-Road Racing
- Street Performance
- Most 4, 6, and 8 cylinder engines
